Hey guys! Today, we're diving deep into setting up pfSense within VirtualBox. If you're looking to create a secure and isolated network for testing, or just want to play around with pfSense without dedicating hardware, you're in the right place. This guide will walk you through each step, making it super easy to follow along. Let's get started!

Why Use pfSense in VirtualBox?

Before we jump into the configuration, let's quickly cover why you might want to run pfSense in VirtualBox. First off, it's completely free! You don't need to buy any hardware or software licenses to get started. This makes it perfect for home labs, testing environments, or even just learning about network security. Secondly, it's incredibly flexible. VirtualBox allows you to create virtual networks, simulate different scenarios, and experiment without affecting your physical network. Plus, you can easily snapshot your virtual machine, so if something goes wrong, you can quickly revert to a previous state. Lastly, it's a great way to learn about pfSense. You can explore its features, configure firewall rules, and get comfortable with the interface before deploying it in a production environment. Using pfSense in VirtualBox provides a safe and isolated environment to experiment and learn without any risk to your actual network. Whether you're a seasoned network engineer or a curious beginner, this setup offers a fantastic learning opportunity. You can try out various configurations, test different firewall rules, and explore advanced features like VPNs and traffic shaping, all within the confines of your virtual environment. This hands-on experience is invaluable for understanding how pfSense works and how to effectively manage a network. Moreover, the ability to create snapshots allows you to easily revert to a known working state if you make a mistake or encounter an issue. This makes the learning process much more forgiving and encourages experimentation. By the end of this guide, you'll have a fully functional pfSense virtual machine that you can use for testing, learning, or even as a secure gateway for your home lab. So, let's dive in and get started with the configuration process!

Prerequisites

Okay, before we get our hands dirty, make sure you have a few things ready:

• VirtualBox: Download and install the latest version of VirtualBox from the official website. It's free and available for Windows, macOS, and Linux.
• pfSense ISO: Grab the latest pfSense ISO image from the pfSense website. You'll need this to install pfSense on your virtual machine.
• A Computer: Obviously, you'll need a computer with enough resources to run VirtualBox and pfSense. A decent CPU and at least 4GB of RAM should be sufficient.

Once you've got these prerequisites covered, you're all set to move on to the next step.

Step 1: Creating the Virtual Machine

Alright, let's create our virtual machine in VirtualBox. Fire up VirtualBox and click on the "New" button. A wizard will pop up, asking you for some details about your VM.

1. Name and Operating System:
   • Give your VM a descriptive name, like "pfSense Firewall".
   • Select "BSD" as the type.
   • Choose "FreeBSD (64-bit)" as the version.
2. Memory Size:
   • Allocate at least 1GB (1024MB) of RAM to the VM. pfSense doesn't need a ton of memory, but this will ensure it runs smoothly.
3. Hard Disk:
   • Create a virtual hard disk. Choose the "Create a virtual hard disk now" option.
   • Select "VDI (VirtualBox Disk Image)" as the hard disk file type.
   • Choose "Dynamically allocated" for storage on the physical hard disk. This means the virtual disk will only take up as much space as it needs, up to the maximum size you specify.
   • Set the size of the virtual hard disk to at least 8GB. This should be plenty of space for pfSense and its logs.

Click "Create" and you've got your virtual machine ready to go! Now, let's configure the network settings.

Step 2: Configuring Network Adapters

This is a crucial step. pfSense needs at least two network adapters: one for the WAN (Wide Area Network) and one for the LAN (Local Area Network). The WAN adapter will connect to your physical network (or the internet), and the LAN adapter will connect to your virtual network.

1. Accessing Network Settings:
   • Select your pfSense VM in VirtualBox and click on "Settings".
   • Go to the "Network" tab.
2. Adapter 1 (WAN):
   • Enable Adapter 1.
   • Set "Attached to" to "Bridged Adapter". This will connect the VM directly to your physical network.
   • Select your physical network adapter from the "Name" dropdown. This is the adapter that's connected to the internet.
   • Under "Advanced", set "Promiscuous Mode" to "Allow All". This is necessary for pfSense to capture network traffic.
3. Adapter 2 (LAN):
   • Enable Adapter 2.
   • Set "Attached to" to "Internal Network". This will create a virtual network that only the VM and other VMs on the same internal network can access.
   • Give the internal network a name, like "pfSense_LAN". Make sure to use the same name for any other VMs you want to connect to this network.
   • Under "Advanced", set "Promiscuous Mode" to "Allow All".

Click "OK" to save the network settings. You've now configured the network adapters for your pfSense VM.

Step 3: Installing pfSense

Time to install pfSense on our virtual machine. This is pretty straightforward, just like installing any other operating system.

1. Mounting the ISO:
   • Select your pfSense VM in VirtualBox and click on "Settings".
   • Go to the "Storage" tab.
   • Under "Controller: IDE", click on the empty disk icon.
   • Click on the disk icon next to "Optical Drive" and choose "Choose a disk file...".
   • Select the pfSense ISO image you downloaded earlier.
   • Click "OK" to save the storage settings.
2. Starting the VM:
   • Select your pfSense VM and click on "Start". The VM will boot from the ISO image.
3. Installation Process:
   • Follow the on-screen instructions to install pfSense. Most of the defaults are fine, but here are a few things to keep in mind:
     • When prompted, choose "Accept these Settings" to accept the copyright notice.
     • Select "Install" to start the installation process.
     • Choose "Auto (UFS)" for the disk partitioning.
     • Answer "No" to the question about manual configuration.
     • When the installation is complete, choose "Reboot".
4. Unmounting the ISO:
   • After the VM reboots, go back to the "Storage" tab in the VM settings and remove the ISO image from the virtual drive. This will prevent the VM from booting from the ISO again.

Your pfSense VM is now installed and ready to be configured.

Step 4: Configuring pfSense

Now for the fun part: configuring pfSense. The first thing you'll see after the VM boots is the pfSense console menu. This is where you'll assign the network interfaces.

1. Interface Assignment:
   • At the console menu, type "1" and press "Enter" to select the "Assign Interfaces" option.
   • pfSense will ask if you want to configure VLANs. Answer "No".
   • pfSense will then ask you to enter the WAN interface name. Enter "em0" (or the appropriate interface name if it's different).
   • Next, it will ask you to enter the LAN interface name. Enter "em1" (or the appropriate interface name if it's different).
   • pfSense will ask you to enter the optional interface name. Just press "Enter" to skip this.
   • Finally, pfSense will ask you to confirm the interface assignment. Type "y" and press "Enter" to confirm.
2. Accessing the WebGUI:
   • After the interface assignment is complete, pfSense will display the IP address of the LAN interface. This is the IP address you'll use to access the pfSense webGUI.
   • Open a web browser on a computer that's connected to the same network as the pfSense LAN interface. This could be another VM on the same internal network, or your physical computer if you've configured the LAN interface to be bridged.
   • Type the IP address of the pfSense LAN interface into the address bar of your web browser and press "Enter". You may get a security warning because pfSense uses a self-signed certificate. Just click through the warning to continue.
   • You'll be prompted to enter a username and password. The default username is "admin" and the default password is "pfsense". Log in to the webGUI.
3. WebGUI Configuration:
   • The first thing you'll see is the pfSense setup wizard. Follow the wizard to configure the basic settings for your pfSense firewall.
   • Change the "admin" password to something more secure.
   • Configure the WAN interface to get an IP address automatically via DHCP.
   • Configure the LAN interface with a static IP address, subnet mask, and gateway.
   • Set the DNS servers to your preferred DNS providers.
   • Choose a timezone.

Once you've completed the setup wizard, you'll be taken to the pfSense dashboard. From here, you can configure all of the features of pfSense, including firewall rules, NAT, VPNs, and more.

Step 5: Testing the Configuration

Alright, now that we've got pfSense up and running, let's make sure everything's working as expected. Here are a few things you can do to test the configuration:

• Ping Test: From a computer on the LAN network, try pinging a website on the internet, like google.com. If the ping is successful, it means your pfSense firewall is able to route traffic to the internet.
• Firewall Rules: Create a firewall rule to block traffic to a specific website or IP address. Then, try to access that website or IP address from a computer on the LAN network. If the firewall rule is working correctly, you should be unable to access the website or IP address.
• NAT: Configure NAT (Network Address Translation) to allow computers on the LAN network to access the internet using a single public IP address. Then, try to access the internet from a computer on the LAN network. If NAT is working correctly, you should be able to access the internet without any issues.
• VPN: Set up a VPN (Virtual Private Network) to allow remote users to securely connect to your network. Then, try to connect to the VPN from a remote computer. If the VPN is working correctly, you should be able to access resources on your network as if you were physically connected to the LAN.

By testing these features, you can ensure that your pfSense firewall is properly configured and that your network is secure.

Conclusion

And there you have it! You've successfully configured pfSense in VirtualBox. You can now use this virtual firewall to protect your home network, test new configurations, or learn more about network security. Remember to keep your pfSense installation up to date and to regularly review your firewall rules to ensure that your network remains secure. Happy networking!
